الوصف
-
وحدة المعالجة المركزيةAMD Socket AM5, support for:
AMD Ryzen™ 7000 / Ryzen™ 8000 Series Processors
(Go to GIGABYTE’s website for the latest CPU support list.) -
شرائحAMD B650
-
ذاكرةSupport for DDR5 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MT/s memory modules
2 x DDR5 DIMM sockets supporting up to 96 GB (48 GB single DIMM capacity) of system memory
بنية ذاكرة ثنائية القناة
دعم وحدات الذاكرة DIMM 1Rx8 / 2Rx8 / 1Rx16 غير المخزنة ECC
Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules
(The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to “Memory Support List” on GIGABYTE’s website for more information.) -
الرسومات على متن الطائرةمعالج رسومات مدمج:
– 1 x DisplayPort, supporting a maximum resolution of 3840×2160@144 Hz
* Support for DisplayPort 1.4 version.- 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz
* Support for HDMI 2.1 version and HDCP 2.3.
** Support for native HDMI 2.1 TMDS compatible ports.(Graphics specifications may vary depending on CPU support.) -
الصوتبرنامج Realtek® Audio CODEC
صوت عالي الجودة
2/4 / 5.1 / 7.1 قناة
* You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. -
LANRealtek® GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)
-
فتحات التوسعة1 × فتحة PCI Express x16 (PCIEX16) ، مدمجة في وحدة المعالجة المركزية:
– AMD Ryzen™ 7000 Series Processors support PCIe 4.0 x16 mode
– AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode
– AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode
* The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot.
شرائح:
– 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1(PCIEX1) -
واجهة التخزين1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2580 SSDs:
– AMD Ryzen™ 7000 Series Processors support PCIe 4.0 x4/x2 SSDs
– AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
– AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs
4 موصلات SATA 6 جيجابت / ثانية
RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices
RAID 0, RAID 1, and RAID 10 support for SATA storage devices -
يو اس بيوحدة المعالجة المركزية:
– 2 x USB 3.2 Gen 1 ports on the back panel
– 1 x USB 2.0/1.1 port on the back panel
شرائح:
– 2 x USB 3.2 Gen 1 ports available through the internal USB header
– 7 x USB 2.0/1.1 ports (3 ports on the back panel, 4 ports available through the internal USB headers) -
موصلات الإدخال / الإخراج الداخلية1 x 24-pin ATX موصل الطاقة الرئيسي
1 × 8-pin ATX 12V موصل الطاقة
1 × رأس مروحة وحدة المعالجة المركزية
2 × موصلات مروحة النظام
1 × رأس شريط LED قابل للتوجيه
1 × رأس شريط LED RGB
1 × موصل M.2 Socket 3
4 موصلات SATA 6 جيجابت / ثانية
1 × رأس اللوحة الأمامية
1 × رأس صوت اللوحة الأمامية
1 × رأس USB 3.2 Gen 1
2 × موصلات USB 2.0 / 1.1
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 / GC-TPM2.0 SPI V2 module only)
1 × طائر CMOS واضح -
موصلات اللوحة الخلفية4 منافذ USB 2.0 / 1.1
1 × منفذ لوحة مفاتيح / ماوس PS / 2
1 × زر Q-Flash Plus
2 × منافذ USB 3.2 Gen 1
1 × ديسبلايبورت
1 × منفذ HDMI
1 × منفذ RJ-45
3 مقابس صوت -
وحدة تحكم الإدخال / الإخراجشريحة تحكم iTE® I / O
-
مراقبة H / Wكشف الجهد
كشف درجة الحرارة
كشف سرعة المروحة
كشف معدل تدفق تبريد المياه
تحذير تعطل المروحة
التحكم في سرعة المروحة
* يعتمد دعم وظيفة التحكم في سرعة المروحة على المروحة التي تقوم بتثبيتها. -
BIOS1 × 256 ميجابت فلاش
استخدام AMI UEFI BIOS المرخص
PnP 1.0a ، DMI 2.7 ، WfM 2.0 ، SM BIOS 2.7 ، ACPI 5.0 -
خصائص فريدةSupport for GIGABYTE Control Center (GCC)
* Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.Support for Q-Flash
دعم Q-Flash Plus -
البرامج المجمعةNorton® Internet Security (إصدار OEM)
LAN bandwidth management software -
نظام التشغيلSupport for Windows 11 64-bit
دعم لنظام التشغيل Windows 10 64 بت -
شكل عاملMicro ATX Form Factor; 23.0cm x 22.5cm
