| التوفر | متوفر في المخزون |
|---|---|
| العلامة التجارية | جيجابايت |
| Supports | Intel® Core™ 14th/ 13th /12th processors |
| Performance | Hybrid 6+2+1 Phases Digital VRM Solution |
| Channel | 4*DIMMs XMP Memory Module Support |
| Storage | 2*PCIe 4.0 x4 M.2 Connectors |
| EZ-Latch | PCIe 4.0×16 Slot with Quick Release Design |
| Network | 2.5GbE LAN & Wi-Fi 6E 802.11ax |
| Connectivity | Rear USB-C® 10Gb/s, DP, HDMI |
| Smart Fan 6 | Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP |
| Q-Flash Plus | Update BIOS Without Installing the CPU, Memory and Graphics Card |
السعر الأصلي هو: 7,499 EGP.6,199 EGPالسعر الحالي هو: 6,199 EGP.
المتوفر في المخزون 1 فقط
احصل على عرض أسعار لمؤسستك يشمل جميع المنتجات أو الخدمات او الحلول التي تحتاجها، وسيتم الرد عليك خلال 24 ساعة
| CPU | CPU Socket | LGA1700 |
| Supported Processors | 14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold, and Celeron® Processors | |
| L3 Cache | Varies with CPU | |
| Chipset | Chipset | Intel® B760 Express Chipset |
| Memory | Memory Type | DDR4 |
| Supported Speeds (O.C.) | Up to 5333 MT/s | |
| Supported Speeds (Standard) | Up to 3200 MT/s | |
| DIMM Sockets | 4 x DDR4 | |
| Maximum Capacity | Up to 128 GB (32 GB single DIMM) | |
| Memory Architecture | Dual-channel | |
| ECC Support | ECC Un-buffered DIMM (operates in non-ECC mode) | |
| XMP Support | Extreme Memory Profile (XMP) | |
| Onboard Graphics | Graphics Processor | Integrated Intel® HD Graphics (CPU dependent) |
| HDMI Port | 1 x HDMI 2.1 (up to 4096×2160@60 Hz) | |
| DisplayPort | 2 x DisplayPort 1.2 (up to 4096×2304@60 Hz) | |
| Display Support | Up to triple-display at the same time | |
| Audio | Audio Codec | Realtek® Audio CODEC |
| Audio Channels | 2/4/5.1/7.1-channel | |
| Audio Out | S/PDIF Out support | |
| LAN | LAN Chip | Realtek® 2.5GbE LAN chip |
| LAN Speed | 2.5 Gbps/1 Gbps/100 Mbps | |
| Wireless | Wi-Fi 6E Module | Varies by PCB revision (AMD RZ608, Intel AX210/AX211, Realtek RTL8852CE) |
| Frequency Bands | 2.4/5/6 GHz | |
| Bluetooth | Varies by PCB revision (5.2 or 5.3) | |
| Expansion Slots | PCIe x16 (CPU) | 1 x PCIe 4.0 x16 slot |
| PCIe x1 (Chipset) | 2 x PCIe 3.0 x1 slots | |
| Storage Interface | M.2 Connectors (CPU) | 1 x M.2 (PCIe 4.0 x4/x2) |
| M.2 Connectors (Chipset) | 1 x M.2 (PCIe 4.0 x4/x2) | |
| SATA Connectors | 4 x SATA 6Gb/s | |
| RAID Support | RAID 0, RAID 1, RAID 5, and RAID 10 (for SATA) | |
| USB | Back Panel | 1x USB 3.2 Gen 2 Type-C, 3x USB 3.2 Gen 1, 2x USB 2.0/1.1 |
| Internal Headers | 1x USB 3.2 Gen 1 (for 2 ports), 2x USB 2.0/1.1 (for 4 ports) | |
| Internal I/O | Power Connectors | 1x 24-pin ATX, 1x 8-pin ATX 12V |
| Fan Headers | 1x CPU fan, 3x system fan | |
| LED Headers | 1x addressable LED strip, 1x RGB LED strip | |
| Other Headers | TPM, S/PDIF Out, Serial Port (on older spec) | |
| Buttons/Jumpers | Q-Flash Plus button, reset button/jumper, Clear CMOS jumper | |
| Back Panel Ports | USB Ports | 2x USB 2.0/1.1, 4x USB 3.2 Gen 1 |
| Video Ports | 1x D-Sub (on older spec), 1x HDMI, 2x DisplayPort | |
| Other Ports | 1x PS/2 (on some revisions), 2x SMA antenna, 1x RJ-45, 3x audio jacks | |
| General | I/O Controller | iTE® I/O Controller Chip |
| BIOS | 1x 128 Mbit flash, licensed AMI UEFI BIOS | |
| Unique Features | GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus | |
| Bundled Software | Norton® Internet Security (OEM), LAN bandwidth management | |
| Operating System | Windows 11 64-bit, Windows 10 64-bit | |
| Form Factor | Micro ATX | |
| Dimensions | 24.4cm x 24.4cm (or 23.0cm x 21.5cm for older revision) |
| التوفر | متوفر في المخزون |
|---|---|
| العلامة التجارية | جيجابايت |
| Supports | Intel® Core™ 14th/ 13th /12th processors |
| Performance | Hybrid 6+2+1 Phases Digital VRM Solution |
| Channel | 4*DIMMs XMP Memory Module Support |
| Storage | 2*PCIe 4.0 x4 M.2 Connectors |
| EZ-Latch | PCIe 4.0×16 Slot with Quick Release Design |
| Network | 2.5GbE LAN & Wi-Fi 6E 802.11ax |
| Connectivity | Rear USB-C® 10Gb/s, DP, HDMI |
| Smart Fan 6 | Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP |
| Q-Flash Plus | Update BIOS Without Installing the CPU, Memory and Graphics Card |
