GIGABYTE Z590 AORUS ELITE AX INTEL

Cash. EGP 5,750
Inst. EGP 6325

Availability: 1 in stock

You can pay in installments through

Special Offers

Aramex Cost Calculator

Categories: , , , Tags: , , , , , ,

GIGABYTE Z590 AORUS ELITE AX INTEL





Specifications:

CPU LGA1200 package:
1.  11th Generation Intel® Core™ i9 processors / Intel® Core™ i7 processors / Intel® Core™ i5 processors
2.  10th Generation Intel® Core™ i9 processors / Intel® Core™ i7 processors / Intel® Core™ i5 processors / Intel® Core™ i3 processors/ Intel® Pentium® processors / Intel® Celeron® processors*
* Limited to processors with 4 MB Intel® Smart Cache, Intel® Celeron® G5xx5 family.
3. L3 cache varies with CPU
(Please refer to “CPU Support List” for more information.)
Chipset Intel® Z590 Express Chipset
Memory 1.      11th Generation Intel® Core™ i9/i7/i5 processors:
Support for DDR4 5400 (O.C)/ DDR4 5333(O.C.)/ DDR4 5133(O.C.)/DDR4 5000(O.C.)/4933(O.C.)/4800(O.C.)/ 4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 MHz memory modules2.      10th Generation Intel® Core™ i9/i7 processors:
Support for DDR4 2933/2666/2400/2133 MHz memory modules3.      10th Generation Intel® Core™ i5/i3 /Pentium®/Celeron® processors:
Support for DDR4 2666/2400/2133 MHz memory modules
4.      4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
5.      Dual channel memory architecture
6.      Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
7.      Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
8.      Support for Extreme Memory Profile (XMP) memory modules
(Please refer “Memory Support List” for more information.)
Onboard Graphics Integrated Graphics Processor-Intel® HD Graphics support:
1 x DisplayPort, supporting a maximum resolution of 4096×2304@60 Hz
* Support for DisplayPort 1.2 version and HDCP 2.3.
(Graphics specifications may vary depending on CPU support.)
Audio Realtek® ALC1220-VB codec
* The back panel line out jack supports DSD audio
High Definition Audio
2/4/5.1/7.1-channel
Support for S/PDIF Out
LAN Realtek® 2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit)
Wireless Communication module Intel® Wi-Fi 6 AX201:

1.      WIFI a, b, g, n, ac with wave 2 features, ax, supporting 2.4/5 GHz Dual-Band
2.      BLUETOOTH 5.1
3.      Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
* Actual data rate may vary depending on environment and equipment.

Expansion Slots 1 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
(The PCIEX16 slot conforms to PCI Express 4.0 standard.)*
*Supported by 11th Generation processors only.
1 x PCI Express x16 slot, running at x4 (PCIEX4)
1 x PCI Express x1 slot
(PCIEX4 and PCIEX1 slots conform to PCI Express 3.0 standard.)
Multi-Graphics Technology Support for AMD Quad-GPU CrossFire™ and 2-Way AMD CrossFire™ technologies
Storage Interface CPU:

1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)*
*Supported by 11th Generation processors only.

Chipset:

1.      1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD support) (M2B_SB)
2.      1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD support) (M2P_SB)
3.      6 x SATA 6Gb/s connectors
Support for RAID 0, RAID 1, RAID 5, and RAID 10
* Refer to “1-7 Internal Connectors,” for the installation notices for the M.2 and SATA connectors.
Intel® Optane™ Memory Ready

USB Chipset:

1.      1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2×2 support
2.      1 x USB Type-C® port with USB 3.2 Gen 2 support, available through the internal USB header
3.      2 x USB 3.2 Gen2 Type-A ports (red) on the back panel
4.      5 x USB 3.2 Gen1 ports (3 ports on the back panel, 2 ports available through the internal USB header)

Chipset+2 USB 2.0 Hub:

8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)

Internal I/O Connectors 1.      1 x 24-pin ATX main power connector
2.      1 x 8-pin ATX 12V power connector
3.      1 x 4-pin ATX 12V power connector
4.      1 x CPU fan header
5.      1 x water cooling CPU fan header
6.      3 x system fan headers
7.      1 x system fan/water cooling pump header
8.      2 x addressable LED strip headers
9.      2 x RGB LED strip headers
10.  6 x SATA 6Gb/s connectors
11.  3 x M.2 Socket 3 connectors
12.  1 x front panel header
13.  1 x front panel audio header
14.  1 x USB Type-C® header, with USB 3.2 Gen 2 support
15.  1 x USB 3.2 Gen1 header
16.  2 x USB 2.0/1.1 headers
17.  2 x Thunderbolt™ add-in card connectors
18.  1 x Trusted Platform Module header (For the GC-TPM2.0 SPI / GC-TPM2.0 SPI 2.0 module only)
19.  1 x Clear CMOS jumper
20.  1 x Q-Flash Plus button
*All fan headers are subject to support AIO_Pump, Pump and high performance fan with the capability of delivering up to 2A/12V @ 24W
Back Panel Connectors 1.      1 x USB Type-C® port, with USB 3.2 Gen 2×2 support
2.      2 x USB 3.2 Gen 2 Type-A ports (red)
3.      3 x USB 3.2 Gen 1 ports
4.      4 x USB 2.0/1.1 ports
5.      2 x SMA antenna connectors (2T2R)
6.      1 x DisplayPort
7.      1 x RJ-45 port
8.      1 x optical S/PDIF Out connector
9.      5 x audio jacks
I/O Controller iTE® I/O Controller Chip
H/W Monitoring 1.      Voltage detection
2.      Temperature detection
3.      Fan speed detection
4.      Water cooling flow rate detection
5.      Fan fail warning
6.      Fan speed control
* Whether the fan speed control function is supported will depend on the fan you install.
BIOS 1.      1 x 256 Mbit flash
2.      Use of licensed AMI UEFI BIOS
3.      PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features 1.      Support for APP Center
* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
@BIOS
EasyTune
Fast Boot
Game Boost
ON/OFF Charge
RGB Fusion
Smart Backup
System Information Viewer
2.      Support for Q-Flash Plus
3.      Support for Q-Flash
4.      Support for Xpress Install
Bundled Software 1.      Norton® Internet Security (OEM version)
2.      Realtek® 8125 Gaming LAN Bandwidth Control Utility
Operating System Support for Windows 10 64-bit
Form Factor ATX Form Factor; 30.5cm x 24.4cm

For more information Click Here
