Description
Specifications
Capacity : 32GB (2x16GB)
Memory Type : DDR5
Interface : 288PIN
Standard : JEDEC & Intel XMP 3.0 & EXPOTM
Speed
5600MT/s1
6000MT/s1(LD5FU016G-R6000GDGA: CL34-38-38-76 ;LD5BU016G-R6000GDLA: CL30-36-36-68 )
6400MT/s1
6800MT/s1
7200MT/s1
CAS Latency
5600MT/s :CL32-36-36-68
6000MT/s:CL30-36-36-68 /CL34-38-38-76
6400MT/s:CL32-38-38-76
6800MT/s:CL34-45-45-108
7200MT/s:CL34-42-42-84
Voltage
5600MT/s :1.2V
6000MT/s:1.35V(CL30-36-36-68 ) /1.3V(CL34-38-38-76)
6400MT/s:1.4V(CL32-38-38-76)
6800MT/s:1.4V(CL34-42-42-84)
7200MT/s:1.4V(CL34-42-42-84)
Operating Temperature
0°C to 85°C(Tcase)
Storage Temperature
-55°C to 100°C
Module Size
L140 x W43.3 x H7.9mm (with heat spreader)
Warranty
Lifetime limited warranty
1Speeds based on internal testing. Actual performance may vary.
2Lifetime limited warranty is limited to 10 years from purchase in Germany and regions not recognizing lifetime warranty.
In case Lexar products are used in a system which may not operate in accordance with specifications as advertised by Lexar, or used together with other kits or memory modules from other manufacturers, Lexar will not guarantee that products meet the above specifications. Furthermore, Lexar will not guarantee that products meet the above specifications if a single module is paired with another manufacturers’ DRAM module to operate as dual kit.
[Product page only:] Product appearance, performance, software offerings, and packaging may vary depending on ship date and available inventory.
Product Numbers
Global
Capacity
#Part
32GB (2x16GB)
7200MT/s
LD5U16G72C34LA-RGD
32GB (2x16GB)
6800MT/s
LD5U16G68C34LA-RGD
32GB (2x16GB)
6800MT/s
LD5U16G68C34WA-RGD
32GB (2x16GB)
6400MT/s
LD5EU016G-R6400GDWA
32GB (2x16GB)
6400MT/s
LD5EU016G-R6400GDLA
32GB (2x16GB)
6000MT/s
LD5FU016G-R6000GDGA
32GB (2x16GB)
5600MT/s
LD5AU016G-R5600GDGA
