Total Cores20
# of Performance-cores8
# of Efficient-cores12
Total Threads28
Max Turbo Frequency5.6 GHz
Intel® Turbo Boost Max Technology 3.0 Frequency ^‡5.6 GHz
Performance-core Max Turbo Frequency5.5 GHz
Efficient-core Max Turbo Frequency4.3 GHz
Performance-core Base Frequency3.4 GHz
Efficient-core Base Frequency2.5 GHz
Cache33 MB Intel® Smart Cache
Total L2 Cache28 MB
Processor Base Power125 W
Maximum Turbo Power253 W

\n

\n

\n

\n

\n

Supplemental Information

\n

\n

Marketing StatusLaunched
Launch DateQ4'23
Embedded Options AvailableNo
Use ConditionsPC/Client/Tablet, Workstation

\n

\n

\n

\n

\n

Memory Specifications

\n

\n

Max Memory Size (dependent on memory type)192 GB
Memory TypesUp to DDR5 5600 MT/s \nUp to DDR4 3200 MT/s
Max # of Memory Channels2
Max Memory Bandwidth89.6 GB/s
ECC Memory Supported ^‡Yes

\n

\n

\n

\n

\n

GPU Specifications

\n

\n

GPU Name^‡Intel® UHD Graphics 770
Graphics Base Frequency300 MHz
Graphics Max Dynamic Frequency1.6 GHz
Graphics OutputeDP 1.4b, DP 1.4a, HDMI 2.1
Execution Units32
Max Resolution (HDMI)^‡4096 x 2160 @ 60Hz
Max Resolution (DP)‡7680 x 4320 @ 60Hz
Max Resolution (eDP - Integrated Flat Panel)‡5120 x 3200 @ 120Hz
DirectX* Support12
OpenGL* Support4.5
OpenCL* Support3.0
Multi-Format Codec Engines2
Intel® Quick Sync VideoYes
Intel® Clear Video HD TechnologyYes
# of Displays Supported ^‡4
Device ID0xA780

\n

\n

\n

\n

\n

Expansion Options

\n

\n

Direct Media Interface (DMI) Revision4.0
Max # of DMI Lanes8
Scalability1S Only
PCI Express Revision5.0 and 4.0
PCI Express Configurations ^‡Up to 1x16+4, 2x8+4
Max # of PCI Express Lanes20

\n

\n

\n

\n

\n

Package Specifications

\n

\n

Sockets SupportedFCLGA1700
Max CPU Configuration1
Thermal Solution SpecificationPCG 2020A
T_JUNCTION100°C
Package Size45.0 mm x 37.5 mm
Max Operating Temperature100 °C

\n

\n

\n

\n

\n

Advanced Technologies

\n

\n

Intel® Gaussian & Neural Accelerator3.0
Intel® Thread DirectorYes
Intel® Deep Learning Boost (Intel® DL Boost) on CPUYes
Intel® Speed Shift TechnologyYes
Intel® Turbo Boost Max Technology 3.0 ^‡Yes
Intel® Turbo Boost Technology ^‡2.0
Intel® Hyper-Threading Technology ^‡Yes
Intel® 64 ^‡Yes
Instruction Set64-bit
Instruction Set ExtensionsIntel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Idle StatesYes
Enhanced Intel SpeedStep® TechnologyYes
Thermal Monitoring TechnologiesYes
Intel® Volume Management Device (VMD)Yes

\n

\n

\n

\n

\n

Security & Reliability

\n

\n

Intel vPro® Eligibility ^‡Intel vPro® Enterprise, Intel vPro® Essentials, Intel vPro® Platform
Intel® Threat Detection Technology (TDT)Yes
Intel® Active Management Technology (AMT) ^‡Yes
Intel® Standard Manageability (ISM) ^‡Yes
Intel® Remote Platform Erase (RPE) ^‡Yes
Intel® One-Click Recovery ^‡Yes
Intel® Hardware Shield Eligibility ^‡Yes
Intel® Control-Flow Enforcement TechnologyYes
Intel® Total Memory Encryption - Multi KeyYes
Intel® AES New InstructionsYes
Secure KeyYes
Intel® OS GuardYes
Intel® Trusted Execution Technology ^‡Yes
Execute Disable Bit ^‡Yes
Intel® Boot GuardYes
Mode-based Execute Control (MBEC)Yes
Intel® Stable IT Platform Program (SIPP)Yes
Intel® Virtualization Technology with Redirect Protection (VT-rp) ^‡Yes
Intel® Virtualization Technology (VT-x) ^‡Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ^‡Yes
Intel® VT-x with Extended Page Tables (EPT) ^‡Yes
