Motherboard Gigabyte B650M S2H DDR5 -AMD (rev. 1.0)

Tags:: Offers
Socket:: Supports AMD Ryzen™ 7000/ Ryzen™ 8000/ Ryzen™ 9000 Series Processors
Channel:: 2*SMD DIMMs with AMD EXPO™ & Intel® XMP Memory Module Support
Storage:: PCIe 4.0 x4 M.2 Connector

CPU	Socket: AMD Socket AM5 Compatibility: AMD Ryzen™ 7000 / Ryzen™ 8000 / Ryzen™ 9000 Series Processors
Chipset	AMD B650
Memory	Speed: DDR5, supporting speeds from 4400 up to 6400 MT/s (O.C.) Slots: 2 x DDR5 DIMM sockets Max. Capacity: Up to 128 GB (64 GB single DIMM capacity) Architecture: Dual channel Module Support: Non-ECC Un-buffered DIMM, AMD EXtended Profiles for Overclocking (AMD EXPO™), and Extreme Memory Profile (XMP) modules
Onboard Graphics	GPU: Integrated Graphics Processor Ports: 1 x D-Sub (max. 1920×1200@60 Hz), 1 x DisplayPort 1.4 (max. 3840×2160@144 Hz), 1 x HDMI 2.1 (max. 4096×2160@60 Hz) Displays: Supports up to 3 displays simultaneously
Audio	Codec: Realtek® Audio CODEC Channels: 2/4/5.1/7.1-channel Features: High Definition Audio
LAN	Controller: Realtek® GbE LAN chip Speed: 1 Gbps/100 Mbps/10 Mbps
Expansion Slots	CPU-connected: 1 x PCI Express x16 (PCIe 4.0, modes vary by CPU) Chipset-connected: 1 x PCI Express x1 (PCIe 3.0)
Storage Interface	M.2: 1 x M.2 connector (CPU-integrated, PCIe 4.0 x4/x2) SATA: 4 x SATA 6Gb/s connectors RAID Support: 0, 1, and 10 for both NVMe SSDs and SATA devices
USB Ports	Rear Panel (CPU): 2 x USB 3.2 Gen 1, 1 x USB 2.0/1.1 Rear Panel (Chipset): 3 x USB 2.0/1.1 Internal Headers (Chipset): 2 x USB 3.2 Gen 1, 4 x USB 2.0/1.1
Internal I/O Connectors	Power: 24-pin ATX main power, 8-pin ATX 12V Fans: 1 x CPU fan, 2 x system fan LED: 1 x addressable LED strip, 1 x RGB LED strip Others: M.2 Socket 3, SATA 6Gb/s, front panel headers, TPM header, Clear CMOS jumper
Back Panel Connectors	Legacy: 1 x PS/2 keyboard/mouse port USB: 4 x USB 2.0/1.1, 2 x USB 3.2 Gen 1 Video: 1 x D-Sub, 1 x DisplayPort, 1 x HDMI Network: 1 x RJ-45 port Audio: 3 x audio jacks Other: Q-Flash Plus button
I/O Controller	iTE® I/O Controller Chip
H/W Monitoring	Features: Voltage, temperature, fan speed, water cooling flow rate detection, fan fail warning, fan speed control
BIOS	Type: 1 x 256 Mbit flash, licensed AMI UEFI BIOS Standards: PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features	Support for GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus
Bundled Software	Norton® Internet Security (OEM version), LAN bandwidth management software
Operating System	Compatibility: Windows 11 64-bit, Windows 10 64-bit
Form Factor	Micro ATX (23.0cm x 22.5cm)
